| 원래 장소: | 중국 산동성 |
|---|---|
| 브랜드 이름: | SH |
| 인증: | ISO9001,CE |
| 모델 번호: | SHJM350, SHJM650, SHJM800 |
| 최소 주문 수량: | 1 세트 |
| 가격: | US $7,500-13,950 / Set |
| 포장 세부 사항: | 철재 프레임 포장 또는 컨테이너 부하 |
| 배달 시간: | 15 일 이내에 |
| 지불 조건: | T/T, Western Union |
| 공급 능력: | 1000은 / 년에서 설정합니다 |
| 이름: | 정확성 세로켜는톱기 띠톱 | 상태: | 새로운 |
|---|---|---|---|
| 유형: | 밴드 쏘 | 주요 모터 파워: | 15kw, 18.5kw, 22kw |
| 먹이 모터: | 1.1kW, 1.5kW | 바퀴 직경을 톱으로 켜세요: | 700mm |
| 가장 큰 톱니 너비: | 800mm | 맥스. 처리 높이: | 220mm |
| 수유 속도: | 인버터, 조정할 수 있는 속도 | 보증:: | 1 년 |
| 애프터 판매 서비스 제공: | 작동하고 훈련하는 온라인 지원, 비디오 기술 지원 | ||
| 강조하다: | electric horizontal bandsaw sawmill,precision wood resaw machine,industrial horizontal sawing equipment |
||
For high-volume woodworking operations, achieving flawless, consistent cuts isn't just a goal—it's a necessity for profitability. An industrial precision resaw bandsaw is engineered to deliver exactly that: unparalleled accuracy and efficiency in every cut. This machine transforms raw lumber into high-value products by maximizing yield and ensuring a superior finish, directly boosting your bottom line through reduced waste and increased output.
Unmatched Cutting Accuracy & Consistency
Benefit: Produce glue-ready laminates and perfectly dimensioned lumber with exceptional smoothness, minimizing the need for secondary planing or sanding.
Features Behind the Benefit: A sophisticated fence system ensures precise workpiece positioning, while computer-balanced wheels and ultra-rigid construction eliminate vibration for dead-straight cuts.
Industrial-Grade Construction for Demanding Environments
Benefit: Experience rock-solid stability and durability that stands up to the rigors of continuous production, ensuring long-term reliability and minimal downtime.
Features Behind the Benefit: Built with heavy-duty components like solid cast-iron wheels, robust trunnions, and a large, stable cast-iron table that forms an unshakable foundation.
| Horizontal Resaw Band Saw Mills | |||
| Model | SH350 | SH650 | SH800 |
| Saw Wheel Diameter | 710 mm | 710 mm | 710 mm |
| Maximum Cutting Width | 350 mm | 650 mm | 800 mm |
| Maximum working Wood Height | 200 mm | 220 mm | 220 mm |
|
Max Sawing Height
|
100 mm | 110 mm | 110 mm |
|
Min Sawing Thickness
|
2 mm | 2mm | 2mm |
| Feeding speed | Variable Frequency Adjusted Speed | ||
| Main Electric Motor Power | 15 KW | 18.5 KW | 18.5KW |
| Up/down motor | 0.37kw | 0.37kw | 0.37kw |
| Feeding motor | 1.1kw | 1.1kw | 1.5kw |
| Machine Weight | 1000 KG | 1200 KG | 1400 KG |
Precision Slice Horizontal Band Sawmill
|
Model
|
SHJM-400
|
SHJM-650
|
SHJM-800
|
|
Saw Wheel Diameter
|
600MM
|
600MM
|
700MM
|
|
Max Sawing Wood Width
|
400MM
|
650MM
|
800MM
|
|
Max Sawing Height
|
110MM
|
||
|
Min Sawing Thickness
|
2MM
|
||
|
Feeding Speed
|
0.1-30 Meters/Minute
|
||
|
Motor Power
|
15KW
|
18.5KW
|
22KW
|
|
Feeding Motor
|
0.75KW |
0.75KW
|
1.5KW
|
This machine is purpose-built for industrial production settings, cabinet shops, and specialized mills focused on high-volume, precision work. If your operations involve frequently breaking down thick stock or require the ability to produce thin, consistent slices of wood with a flawless finish, a precision resaw is an indispensable asset.
